HIGH TRAIL PERFORMANCE FOR TRX-4M
Small-scale adventure takes a big leap in performance with the TRX-4M™ Chevrolet® K10 High Trail™ Edition. The lifted High Trail pickup offers over 35% more center ground clearance than a standard TRX-4M with an extended wheelbase for even more all-terrain capability. Oversize Mickey Thompson® Baja Pro™ XS tires enhance traction and give K10 a dramatic lifted truck profile. From indoor fun to outdoor adventure, TRX-4M K10 High Trail Edition delivers the quality and performance you expect from Traxxas.
LONG ARM LIFT KIT
The High Trail edition’s Factory Installed Long Arm Lift Kit and larger tires raise the center ground clearance over 35% for a dramatic lifted stance. Revised shock mounts and extended links ensure the truck maintains its carefully-tuned suspension geometry for peak performance on challenging terrain.
NEW LARGER 2.4″ TIRES
Larger 2.4″ Mickey Thompson® Baja Pro™ XS replicate the full size tire’s aggressive tread pattern and fill out the High Trail Edition’s wheel wells for an authentic “lifted truck” look. Sticky compound rubber and trail-tuned foam inserts give extra “bite” for superior traction on the trail.
EXTENDED WHEELBASE
The High Trail Edition’s steel frame rails extend the wheelbase out to 162mm to capture the pickup’s real-world proportions perfectly. A longer wheelbase also translates into greater climbing stability and a smoother, more stable ride over rough terrain.
DETAILED CLIPLESS BODY
The TRX-4M Chevrolet K10 clipless body holds tight on the trail but releases in just seconds with a hidden latching system to preserve its clean lines. The tough ABS body featured molded-in color with highly detailed chrome trim for complete scale authenticity.
FEATURES
- Clipless ABS Body
- Highly-detailed licensed Chevrolet K10 Body
- Molded-in color won’t chip or flake
- Chrome side mirrors, door handles, & wipers
- LED headlights
- Heavy duty latching clips
- Hold tightly on the trail
- Release in just seconds
- Highly-detailed licensed Chevrolet K10 Body
- Long Arm Lift Kit
- Revised shock towers
- Extended 4-link suspension
- Heavy duty rod ends
- ECM-2.5™ Electronic Control Module
- Incorporates ESC, receiver, and LED controller in one chassis
- Fully waterproof for all-weather fun
- Three drive profiles
- Sport Mode – forward / brake / reverse
- Trail Mode – forward / brake / reverse / with trail-tuned drag brake in neutral
- Crawl Mode – forward / instant reverse – no neutral with 100% hill holding brake
- Traxxas EZ-Set® one-button setup
- Built-in Pro Scale® LED functionality
- Two-stage low voltage protection (LVD)
- Motor overload protection
- TQ™ 2.4GHz Transmitter
- Full-size 2-channel transmitter
- All-day comfort with precise long-range control
- Motor
- Powerful Titan® 87-turn brushed motor
- Fixed gear mesh doesn’t require adjustment
- Forward mounting position for improved crawling dynamics
- Extended Heavy Duty Steel Ladder Frame
- Deep C-channel design
- Thicker center section for maximum rigidity
- Rails run from bumper to bumper
- Drivetrain
- Full-time shaft-driven 4-wheel drive
- Solid steel axles
- Spool-equipped front and rear axles
- Heavy duty CV center driveshafts
- Optional Transmission Ratios (sold separately)
- Optional Low Range or Speed Gearing transmissions
- Modular design swaps out in minutes
- Optional Low Range or Speed Gearing transmissions
- Steering
- Heavy duty 2065T steering servo
- Metal main gear
- Superior 45° steering angle
- Direct steering (no servo saver)
- Heavy duty 2065T steering servo
- Low-CG Battery Tray
- Concentrates weight lower for improved stability
- Wide rubber strap secures battery in place
- Oil-Filled GTM™ Shocks
- Provides smooth controlled damping
- Realistic driving body movements
- Adjustable pre-load spacers
- Easily refreshed with available rebuild kits
- Wheels and Tires
- 1″ Replica 8-hole chrome mag wheels
- 7mm hex
- Pre-mounted Mickey Thompson® Baja Pro™ XS tires
- Trail-tuned rubber compound
- 1″ Replica 8-hole chrome mag wheels
- Battery and Charger Included
- High-capacity 2-cell LiPo battery
- 7.4 volts
- 750mAh for over an hour of run time
- 2-amp USB-powered fast charger
- iD® technology for faster, safer charging
- High-capacity 2-cell LiPo battery
- Low-Maintenance Self-Lubricating Bushings
- Durable Hex hardware
Specifications
| Length: | 10.6 inches (269mm) |
|---|---|
| Front Track: | 5.0 inches (127mm) |
| Rear Track: | 5.0 inches (127mm) |
| Center Ground Clearance: | 1.57 inches (40mm) |
| Weight (with battery): | 1.03lbs (468g) |
| Height: | 5.0 inches (127mm) |
| Wheelbase: | 6.38 inches (162mm) |
| Approach Angle: | 62° |
| Breakover Angle: | 51.5° |
| Departure Angle: | 52° |
| Shock Length (front and rear): | 2.0 inches (51mm) |
| Hex Size: | 7mm |
| Differential Type: | Fully Locked; 2:1 Axle Ratio |
| Wheels (front and rear): | 1.0 x 0.49 inches (25.4 x 12.5mm) |
| Tires (front and rear): | 2.4 x 1.0 inches (61.9 x 25.6mm) |
| Electronic Control Module: | ECM-2.5™ (Combo ESC, Receiver, Lighting Control*) |
| Motor (electric): | Titan® 180 87T |
| Chassis Structure/Material: | Steel Ladder Frame with Nylon Composite Crossmembers |
| Brake Type: | Electronic “Hill Hold” |
| Drive System: | Shaft-Driven 4WD |
| Steering: | Axle-Mounted Servo |
| Radio System: | TQ™ 2.4GHz 2-Channel Transmitter |
| Servo: | #2065T Heavy Duty Waterproof |
| Skill Level: | 1 |
| Battery Tray: | 50.5mm L X 31mm W |
| *Requires accessory Pro Scale LED Light Kit, sold separately | |
Karbist leiad
- Kokkupandud TRX-4m mudel koos värvitud kerega
- TQi™ 2.4GHz raadiosüsteem
- Juhendid, joonised ja lihtsamad tööriistad
- AA patareid saatja jaoks
- 2S 750mAh LiPo aku ja USB toitega laadija
Juurde vajad
- Mitte midagi! Kõik vajalik on olemas.
