Futaba S-U300 Servo Standard 4.5kg/0.19s S.BUS2

This is a new Futaba standard servo with S.BUS(2) function.



Specs:

• Plastic Gears
• Digital / S.BUS2
• Input Voltage: 4.8-6V
• Torque @ 4.8V: 3.5kg/cm
• Torque @ 6.0V: 4.5kg/cm
• Speed @ 4.8V: 0.23s/60°
• Speed @ 6.0V: 0.19s/60°
• Size: 40.4 x 19.8 x 36.0 mm
• Weight: 36g

The S-U300 will replace these Futaba servos in the near future:

• S148
• S3003
• S3005
• FS100
