Hobbywing UBEC 10A HV 3-14S

The UBEC uses a high-performance DC voltage regulator with switching module that draws its voltage from 3-14S LiPos. With it the regulator gives out 10A extremely stable or for a short amount of time 25A.Therefore this UBEC provides power for all kinds of RC modell devices. It is also suitable for fixed wing aircraft.

Features:

Highly efficient DC-DC regulator chip for a transmission efficiency of over 90%.

An all-metal housing design helps conduct heat and reduces electromagnetic interference.

Adjustable UBEC output voltage (6.0V / 7.4V / 8.4V) applicable for servos with different voltages.

Multiple protection functions: overcurrent protection, output short circuit protection, overheating protection, safe and reliable.

LED display to show the status of the UBEC.

Specifications

• Input Voltage: 3-14S LiPo
• Output Voltage: 6.0V / 7.4V / 8.4V (adjustable)
• Current cont./peak: 10A / 25A
• Dimensions: 55x25x12mm
• Weight: 35g
